64.5″ TCL 65P7L – Full Specifications

Sofa-distance viewing in a mid-sized lounge suits the TCL 65P7L (64.5 in), a 65-class Google TV with quantum dot colour on an HVA panel.

64.5″ · 1.778:1 / 16:9 · MODEL YEAR 2026
tcl●TV
tcl TV
Add as preferred source
Display
64.5 in, HVA, Direct LED, 3840 x 2160 (4K)
64.5
Refresh rate
50 Hz / 60 Hz
50 Hz
Dimensions
1444 x 831 x 69.5 mm
1444
Weight
15.8 kg
15.8 k
Processor
AiPQ

Overview

Sofa-distance viewing in a mid-sized lounge suits the TCL 65P7L (64.5 in), a 65-class Google TV with quantum dot colour on an HVA panel. It shows 3840 × 2160 at 68 ppi and 50/60 Hz with direct LED backlight, Dolby Vision, HDR10+ and HLG. Two 10 W speakers add Dolby Atmos and DTS Virtual:X. Weight is 16 kg with the stand and 15.8 kg without it, the VESA pattern is 400 × 300 mm, and three HDMI inputs and two USB ports are provided.

  • 64.5 in HVA, 3840 × 2160, 68 ppi
  • 50/60 Hz, direct LED, quantum dot
  • Dolby Vision, HDR10+, HLG
  • 3 HDMI inputs, 2 × USB
  • 16 kg with stand, 400 × 300 VESA

Pros & Cons

Pros
  • Large 65-inch screen at only 16 kg
  • Slim unibody design keeps depth low
  • Two USB ports for media and accessories
  • Quantum dot panel lists 93 percent DCI-P3
  • DTS Virtual:X adds virtual surround processing
Cons
  • The 65P7L is limited to 50/60 Hz
  • Speaker rating is just 2 × 10 W
  • Only 3 HDMI ports for consoles, a soundbar and a streamer
  • VA-type panel loses some contrast and colour from off-centre seats

Score & Ratings

7.2/10 Great
Design
7
Display
7
Color
8
Performance
7
Connectivity
7
Television Identity & Market 6
Specification Value
Brand TCL
Series P7L
Model 65P7L
Full Product Name TCL 65P7L
Model Year 2026
Available Colors Black
Screen Geometry & Format 8
Specification Value
Screen Size 64.5 in
Marketed Screen Size 64.5 in
Exact Diagonal 1639 mm / 163.9 cm / 64.5276 in / 5.3773 ft
Aspect Ratio 1.778:1 / 16:9
Active Display Width 1428.48 mm / 142.848 cm / 56.2394 in / 4.6866 ft
Active Display Height 803.52 mm / 80.352 cm / 31.6346 in / 2.6362 ft
Display Area 95.65 %
3D Support No

64.5" Display Size (163.8 cm) 16:9

163.8cm 64.5" 142.8 cm / 56.2" 144.4 cm / 56.9" (overall unit) 80.4 cm 31.6" 83.1 cm 32.7" (overall)

Resolution at a Glance

3840×2160 This screen 8K — 7,680×4,320 4K — 3,840×2,160 FHD — 1,920×1,080 HD — 1,280×720 8.3 MP — 4× the pixels of Full HD
Panel Architecture & Light Control 8
Specification Value
Panel Manufacturer CSOT
Panel Type HVA
Quantum Dot Yes
Quantum Dot Technology Super Quantum Dot (Super QLED)
Backlight Type Direct LED
Panel Bit Depth 10 bits (8 bits + FRC)
FRC Yes
Display Colors 1073741824 colors / 30 bits
Resolution, Scaling & Signal 4
Specification Value
Native Resolution 3840 x 2160 pixels / Ultra HD (UHD) / 4K / 2160p
Pixel Density 68 ppi / 26 ppcm
Pixel Pitch 0.372 mm / 0.0372 cm / 0.0146 in / 0.0012 ft
Native 4K Support Yes
◑ Luminance, Blacks & Contrast 4
Specification Value
Typical Brightness 400 cd/m²
Viewing Angles 178 ° / 178 °
Horizontal Viewing Angle 178 °
Vertical Viewing Angle 178 °
Color Reproduction & Calibration 3
Specification Value
DCI-P3 Coverage 93 %
Wide Color Gamut Yes
Quantum Dot Color Yes
RECOMMENDED VIEWING DISTANCE 65"
Viewing Distance = 1.5–2.5 × Screen Size
65" Centre screen at eye level (~42") 65" TV → 8.1–13.4 ft viewing distance

24° field of view — Comfortable, relaxed viewing.

HDR Formats & Tone Mapping 6
Specification Value
HDR Support
  • Dolby Vision
  • HDR10+
  • HDR10
  • HLG
HDR Formats
  • Dolby Vision
  • HDR10+
  • HDR10
  • HLG
HDR10 Yes
HDR10+ Yes
Dolby Vision Yes
HLG Yes
Motion Processing & Response 5
Specification Value
Maximum Refresh Rate 50 Hz / 60 Hz
Refresh Rate Range 50 Hz / 60 Hz
Vertical Frequency 50 Hz / 60 Hz
Motion Processing MEMC (Motion Estimation Motion Compensation)
Motion Estimation Yes
Console, VRR & Game Tools 3
Specification Value
Auto Low Latency Mode Yes
Game Bar AI Gaming with Game Bar
Game Master Yes
Picture Intelligence & AI 6
Specification Value
AI Contrast Yes
AI Color Yes
AI Clarity Yes
AI HDR Enhancement Yes
AI Scene Detection Yes
Art Mode AI Art
Broadcast Tuners & Reception 8
Specification Value
Built-In TV Tuner
  • Yes
Tuner Configuration Analog (NTSC / PAL / SECAM) / DVB-T / DVB-T2 / DVB-C / DVB-S / DVB-S2
Analog Tuner NTSC / PAL / SECAM
Digital Terrestrial Tuner DVB-T
Digital Terrestrial Tuner 2 DVB-T2
Digital Cable Tuner DVB-C
Digital Satellite Tuner DVB-S
Digital Satellite Tuner 2 DVB-S2
Compute, Memory & Storage 10
Specification Value
Processor Brand Name AiPQ
System on Chip RealTek RTD2875P
SoC Model RealTek RTD2875P
CPU Architecture 2x ARM Cortex-A75, 2x ARM Cortex-A55
CPU Cores 4
CPU Frequency 1300 MHz
GPU IMG BXE
RAM Capacity 2 GB
RAM Type DDR4
Internal Storage 16 GB / eMMC 5.1
Smart Platform & System 2
Specification Value
Smart TV Yes
Operating System Google TV
Streaming & Entertainment 5
Specification Value
Netflix Yes
YouTube Yes
Prime Video Yes
Disney+ Yes
Art Gallery Yes
Voice Assistants & Search 2
Specification Value
Amazon Alexa Yes
Google Assistant Yes
HDMI Signal Interface 8
Specification Value
Total HDMI Ports
  • 3
HDMI 2.0 Ports
  • 3× HDMI 2.0
HDMI CEC Yes
Audio Return Channel Yes
Enhanced Audio Return Channel Yes
Auto Low Latency Mode Yes
HDCP Support Yes
HDCP Version 2.3

Ports & Connections

HDMI3USB-A2EtherneteARCOptical AudioSpeaker Out20Antenna / RFCable / Satellite
USB, Audio & Legacy I/O 8
Specification Value
Total USB Ports
  • 2
USB-A 2.0 Ports
  • 1× USB 2.0
USB-A 3.0 Ports
  • 1× USB 3.0
Ethernet Port 1 x RJ45
Optical Audio Output 1 x Optical
Satellite Input 1 x F-type
Antenna Input 1 x RF
Common Interface Slot 1 x CI+ 1.4
Wireless, LAN & Casting 9
Specification Value
LAN Yes
Wi-Fi Wi-Fi
Wi-Fi Standards 802.11a / 802.11b / 802.11g / 802.11n
Bluetooth Bluetooth
Wi-Fi Direct Yes
DLNA Yes
Apple AirPlay Yes
Chromecast Yes
Google Cast Yes
Speaker Layout & Output 6
Specification Value
Built-In Speakers 2 x 10 W / 2.0 CH / 20W / Dolby Atmos / DTS Virtual:X
Speaker Configuration 2.0 CH
Speaker Channels 2.0 CH
Main Speakers 2 x 10 W / 2.0 CH / 20W / Dolby Atmos / DTS Virtual:X
Total Audio Output 20 W
Total Speaker Output 20 W
Sound Formats & Enhancement 2
Specification Value
Dolby Atmos Yes
DTS Virtual:X Yes
Camera & Video Calling 1
Specification Value
Built-In Camera No
Accessibility & Assisted Use 1
Specification Value
Low Blue Light Mode Yes
Photo File Compatibility 4
Specification Value
Image File Formats JPEG / GIF / PNG
JPEG Yes
PNG Yes
GIF Yes
Music Codec Compatibility 8
Specification Value
Audio Formats
  • 3GPP (3rd Generation Partnership Project, .3gp)
  • AAC (Advanced Audio Coding)
  • AAC+
  • aacPlus
  • HE-AAC v1
  • FLAC (Free Lossless Audio Codec, .flac)
  • M4A (MPEG-4 Audio, .m4a)
  • MP3 (MPEG-2 Audio Layer II, .mp3)
  • WMA (Windows Media Audio, .wma)
  • WAV (Waveform Audio File Format, .wav, .wave)
AAC Yes
HE-AAC Yes
FLAC Yes
MP3 Yes
M4A Yes
WMA Yes
WAV Yes
Video Container Compatibility 7
Specification Value
Video Containers
  • 3GPP (3rd Generation Partnership Project, .3gp)
  • AVI (Audio Video Interleaved, .avi)
  • DivX (.avi, .divx, .mkv)
  • H.263
  • H.264
  • MPEG-4 Part 10
  • AVC video
  • H.265
  • MPEG-H Part 2
  • HEVC
  • MKV (Matroska Multimedia Container, .mkv .mk3d .mka .mks)
  • MP4 (MPEG-4 Part 14, .mp4, .m4a, .m4p, .m4b, .m4r, .m4v)
  • +4 more
    • MPEG-4
    • VP9
    • WMV (Windows Media Video, .wmv)
    • Xvid
3GPP Yes
AVI Yes
DivX Yes
MKV Yes
MP4 Yes
WMV Yes
Video Codec Compatibility 7
Specification Value
Video Codecs
  • 3GPP (3rd Generation Partnership Project, .3gp)
  • AVI (Audio Video Interleaved, .avi)
  • DivX (.avi, .divx, .mkv)
  • H.263
  • H.264
  • MPEG-4 Part 10
  • AVC video
  • H.265
  • MPEG-H Part 2
  • HEVC
  • MKV (Matroska Multimedia Container, .mkv .mk3d .mka .mks)
  • MP4 (MPEG-4 Part 14, .mp4, .m4a, .m4p, .m4b, .m4r, .m4v)
  • +4 more
    • MPEG-4
    • VP9
    • WMV (Windows Media Video, .wmv)
    • Xvid
H.263 Yes
H.264 / AVC Yes
H.265 / HEVC Yes
MPEG-4 Yes
VP9 Yes
Xvid Yes
Panel-Only Size & Mass 5
Specification Value
Dimensions Without Stand 1444 x 831 x 69.5 mm
Width Without Stand 1444 mm / 144.4 cm / 56.8504 in / 4.7375 ft
Height Without Stand 831 mm / 83.1 cm / 32.7165 in / 2.7264 ft
Depth Without Stand 69.5 mm / 6.95 cm / 2.7362 in / 0.228 ft
Weight Without Stand 15.8 kg / 34.83 lbs
Assembled TV Size & Mass 5
Specification Value
Dimensions With Stand 1444 x 893 x 320 mm
Width With Stand 1444 mm / 144.4 cm / 56.8504 in / 4.7375 ft
Height With Stand 893 mm / 89.3 cm / 35.1575 in / 2.9298 ft
Depth With Stand 320 mm / 32 cm / 12.5984 in / 1.0499 ft
Weight With Stand 16 kg / 35.27 lbs
Shipping Carton Measurements 5
Specification Value
Box Dimensions 1608 x 1000 x 145 mm
Box Width 1608 mm / 160.8 cm / 63.3071 in / 5.2756 ft
Box Height 1000 mm / 100 cm / 39.3701 in / 3.2808 ft
Box Depth 145 mm / 14.5 cm / 5.7087 in / 0.4757 ft
Box Weight 23.6 kg / 52.03 lbs
Exterior Styling & Stand Footprint 6
Specification Value
Stand Width 1134 mm / 113.4 cm / 44.6457 in / 3.7205 ft
Stand Depth 320 mm / 32 cm / 12.5984 in / 1.0499 ft
Stand Footprint 1134 mm x 320 mm
Chassis Color Black
Design Name Slim Unibody Design
Slim Design Yes
Wall Mounting & Installation 8
Specification Value
VESA Mount 400 x 300 mm
VESA Interface 400 x 300 mm
VESA Size 400 x 300 mm
Removable Stand Yes
Height Adjustment No
Swivel Adjustment No
Tilt Adjustment No
Pivot Adjustment No
Electrical Load & Efficiency 6
Specification Value
Power Input 100 V - 120 V / 220 V - 240 V
110V Input Range 100 V - 120 V
220V Input Range 220 V - 240 V
AC Frequency 50 Hz - 60 Hz
Sleep Consumption 0.5 W
Standby Consumption 0.5 W
Environmental Operating Limits 4
Specification Value
Operating Temperature 5 °C - 35 °C / 41 °F - 95 °F
Operating Humidity 20 % - 80 %
Storage Temperature -15 °C - 45 °C / 5 °F - 113 °F
Storage Humidity 10 % - 90 %
Gaming Validation & Compatibility 1
Specification Value
ALLM Auto Low Latency Mode (ALLM)
In-the-Box Components 4
Specification Value
Remote Control Voice remote control
Remote Type Voice remote control
Remote Voice Control Yes
Screen Size 64.5 in
⚡

Estimated Running Cost

Based on this product's rated power draw, not an independent lab measurement — actual usage varies with settings and content.

Daily—
Monthly—
Annually—

Draws more power than 82% of the 447 comparable displays we track.
