tcl TCL 65A300 Pro EU – Full Specifications TV
RATED
Excellent
9.0/10

64.5″ TCL 65A300 Pro EU – Full Specifications

Most TV listings skip brightness, so the numbers TCL does publish on the TCL 65A300 Pro EU are worth noting: 300 nits typical, 330 nits peak and a 6000:1 static contrast ratio o...

64.5″ · 16:9 · MODEL YEAR 2024
tcl●TV
tcl TV
Add as preferred source
Display
64.5 in, VA, 3840 x 2160 pixels
64.5
Refresh rate
48 Hz - 144 Hz
48 Hz
Dimensions
1452 mm x 837 mm x 27.9 mm
1452
Weight
22.5 kg / 49.6 lbs
22.5 k
Processor
AIPQ Pro

Overview

Most TV listings skip brightness, so the numbers TCL does publish on the TCL 65A300 Pro EU are worth noting: 300 nits typical, 330 nits peak and a 6000:1 static contrast ratio on a 64.5-inch 4K VA panel. With Dolby Vision, HDR10+ and Google TV, plus a 144 Hz range for console gaming, it covers the basics well for a family living room. It weighs 23.5 kg with its stand, and edge lighting means contrast depends on the VA panel, not local dimming.

  • 64.5-inch VA 4K UHD TV at 68 ppi (A300 Pro EU)
  • 48–144 Hz refresh with variable refresh
  • 300 nits typical (330 nits peak), 6000:1 static contrast
  • HDR10, HDR10+ and Dolby Vision, Google TV
  • Edge LED, 2 × 10 W speakers, 23.5 kg, 2024

Pros & Cons

Pros
  • Published 300 nits and 6000:1 contrast set expectations clearly
  • 144 Hz range suits current consoles
  • Dolby Vision and HDR10+ cover most streaming apps
  • Google TV makes streaming simple
  • Good all-round size for a family living room
Cons
  • 23.5 kg weight needs a sturdy stand or wall mount
  • Edge lighting limits contrast compared with local dimming
  • Speakers are modest at 2 × 10 W
  • Side seats lose some contrast on a VA screen

Score & Ratings

9.0/10 Excellent
Design
9
Display
8
Color
8
Performance
10
Connectivity
10
Television Identity & Market 13
Specification Value
Brand TCL
Series NXTVISION Pro
Model 65A300 Pro EU
Model Alias 65A300PRO EU
Full Product Name TCL NXTVISION Pro 65A300 Pro EU
Model Year 2024
TV Category Premium Design-Focused Tier
Market Position Designer / Ambient TV, NXTFRAME
Primary Use Design-Conscious Premium Home Entertainment
Region / Variant Not specified
Launch Status Model year 2024
Available Colors Off White Bezel and Light Wood Frame
Warranty 1 year standard limited warranty
Screen Geometry & Format 8
Specification Value
Screen Size 64.5 in
Marketed Screen Size 64.5 in
Exact Diagonal 1639 mm (millimeters) / 163.9 cm (centimeters) / 64.5276 in (inches) / 5.3773 ft (feet)
Aspect Ratio 16:9
Active Display Width 1428.48 mm (millimeters) / 142.848 cm (centimeters) / 56.2394 in (inches) / 4.6866 ft (feet)
Active Display Height 803.52 mm (millimeters) / 80.352 cm (centimeters) / 31.6346 in (inches) / 2.6362 ft (feet)
Screen-to-Body Ratio 94.44 %
3D Support No

64.5" Display Size (163.8 cm) 16:9

163.8cm 64.5" 142.8 cm / 56.2" 145.2 cm / 57.2" (overall unit) 80.4 cm 31.6" 83.7 cm 33" (overall)

Resolution at a Glance

3840×2160 This screen 8K — 7,680×4,320 4K — 3,840×2,160 FHD — 1,920×1,080 HD — 1,280×720 8.3 MP — 4× the pixels of Full HD
Panel Architecture & Light Control 7
Specification Value
Panel Manufacturer CSOT
Panel Type VA
Panel Technology VA
Backlight Type Edge LED
Panel Bit Depth 10 bits (8 bits + FRC)
FRC Yes
Display Colors 1.07 billion colors / 30-bit
Surface Treatment & Viewing Layer 1
Specification Value
Screen Coating Anti-glare / Matte
Resolution, Scaling & Signal 3
Specification Value
Native Resolution 3840 x 2160 pixels
Pixel Density 68 ppi / 26 ppcm
Pixel Pitch 0.372 mm / 0.0146 in
◑ Luminance, Blacks & Contrast 7
Specification Value
Typical Brightness 300 cd/m²
Peak Brightness 330 cd/m²
Static Contrast Static contrast: 6000 : 1
Static Contrast Ratio Static contrast: 6000 : 1
Viewing Angles 178° / 178°
Horizontal Viewing Angle 178 ° (degrees)
Vertical Viewing Angle 178 ° (degrees)
Color Reproduction & Calibration 1
Specification Value
Wide Color Gamut Yes
RECOMMENDED VIEWING DISTANCE 65"
Viewing Distance = 1.5–2.5 × Screen Size
65" Centre screen at eye level (~42") 65" TV → 8.1–13.4 ft viewing distance

24° field of view — Comfortable, relaxed viewing.

HDR Formats & Tone Mapping 8
Specification Value
HDR Support
  • Dolby Vision IQ
  • Dolby Vision
  • HDR10+
  • HDR10
  • HLG
HDR Formats
  • Dolby Vision IQ
  • Dolby Vision
  • HDR10+
  • HDR10
  • HLG
HDR10
  • HDR10
HDR10+ Yes
Dolby Vision Yes
Dolby Vision IQ Yes
HLG HLG (Hybrid Log Gamma)
Dynamic Tone Mapping Yes
Motion Processing & Response 5
Specification Value
Native Refresh Rate 48 Hz - 144 Hz (hertz) / Native - 120 Hz
Maximum Refresh Rate 48 Hz - 144 Hz
Motion Processing Motion Rate 480 MR
Motion Estimation Yes
Input Lag 5.8 ms
Console, VRR & Game Tools 3
Specification Value
Variable Refresh Rate Yes
AMD FreeSync AMD FreeSync Premium
Game Bar Yes
Picture Intelligence & AI 2
Specification Value
AI Picture Engine AI features supported
Ambient Mode Yes
Broadcast Tuners & Reception 10
Specification Value
Built-In TV Tuner
  • Yes
Tuner Configuration
  • Analog (NTSC / PAL / SECAM)
  • DVB-T2
  • DVB-T
  • DVB-C
  • DVB-S
  • DVB-S2
Analog Tuner NTSC / PAL / SECAM
Digital Terrestrial Tuner dvb-t
Digital Terrestrial Tuner 2 dvb-t2
Digital Cable Tuner dvb-c
Digital Satellite Tuner dvb-s
Digital Satellite Tuner 2 dvb-s2
Satellite Input 1× F-type
Antenna RF Input Yes
Compute, Memory & Storage 5
Specification Value
Processor Brand Name AIPQ Pro
System on Chip AIPQ Pro
SoC Model AIPQ Pro
CPU Architecture CPU cores: 4
CPU Cores 4
Smart Platform & System 2
Specification Value
Smart TV Yes
Operating System Google TV (Android 12)
Streaming & Entertainment 5
Specification Value
Netflix Yes
YouTube Yes
Prime Video Yes
Disney+ Yes
Apple TV+ Yes
Voice Assistants & Search 2
Specification Value
Voice Control Yes
Google Assistant Yes
HDMI Signal Interface 5
Specification Value
Total HDMI Ports
  • 4
HDMI 2.1 Ports
  • 2× HDMI 2.1
HDMI 2.0 Ports
  • 2× HDMI 2.0
HDMI CEC Yes
eARC Port Yes

Ports & Connections

HDMI4USB-A2EtherneteARCOptical AudioHeadphoneSpeaker Out20Antenna / RFCable / SatelliteComposite / AV
USB, Audio & Legacy I/O 10
Specification Value
Total USB Ports
  • 2
USB-A 2.0 Ports
  • 1× USB 2.0
USB-A 3.0 Ports
  • 1× USB 3.0
Ethernet Port 1× RJ45
Optical Audio Output 1× S/PDIF
3.5 mm Audio Output 1× 3.5 mm
Headphone Output Yes
Satellite Input 1× F-type
Antenna Input 1× RF
Composite Input Yes
Wireless, LAN & Casting 11
Specification Value
LAN Yes
Wi-Fi Wi-Fi 8
Wi-Fi Standards 802.11a
Bluetooth Bluetooth 5.2
Wi-Fi Direct Yes
DLNA Yes
Apple AirPlay Yes
Apple HomeKit Yes
Chromecast Yes
Google Cast Yes
Miracast Yes
Speaker Layout & Output 5
Specification Value
Built-In Speakers Yes
Speaker Configuration 2 x 10 W
Speaker Channels 2 x 10 W
Total Audio Output 20 W (watts)
Total Speaker Output 20 W (watts)
Sound Formats & Enhancement 2
Specification Value
Dolby Atmos Yes
DTS:X Yes
Camera & Video Calling 1
Specification Value
Built-In Camera No
Connected Home & IoT 1
Specification Value
Apple HomeKit Yes
Photo File Compatibility 4
Specification Value
Image File Formats JPEG / GIF / PNG
JPEG Yes
PNG Yes
GIF Yes
Music Codec Compatibility 8
Specification Value
Audio Formats 3GPP / AAC / AAC+ / aacPlus / HE-AAC v1 / FLAC / M4A / MP3 / WMA / WAV
AAC Yes
HE-AAC Yes
FLAC Yes
MP3 Yes
M4A Yes
WMA Yes
WAV Yes
Video Container Compatibility 7
Specification Value
Video Containers
  • 3GPP
  • AVI
  • DivX (.avi, .divx, .mkv)
  • H.263
  • H.264
  • MPEG-4 Part 10
  • AVC video
  • H.265
  • MPEG-H Part 2
  • HEVC
  • MKV
  • MP4
  • +4 more
    • MPEG-4
    • VP9
    • WMV
    • Xvid
3GPP Yes
AVI Yes
DivX Yes
MKV Yes
MP4 Yes
WMV Yes
Video Codec Compatibility 7
Specification Value
Video Codecs
  • 3GPP
  • AVI
  • DivX (.avi, .divx, .mkv)
  • H.263
  • H.264
  • MPEG-4 Part 10
  • AVC video
  • H.265
  • MPEG-H Part 2
  • HEVC
  • MKV
  • MP4
  • +4 more
    • MPEG-4
    • VP9
    • WMV
    • Xvid
H.263 Yes
H.264 / AVC Yes
H.265 / HEVC Yes
MPEG-4 Yes
VP9 Yes
Xvid Yes
Panel-Only Size & Mass 5
Specification Value
Dimensions Without Stand
  • Width: 1452 mm
  • Height: 837 mm
  • Depth: 27.9 mm
Width Without Stand 1452 mm / 57.1654 in
Height Without Stand 837 mm / 32.9528 in
Depth Without Stand 27.9 mm / 1.0984 in
Weight Without Stand 22.5 kg / 49.6 lbs
Assembled TV Size & Mass 5
Specification Value
Dimensions With Stand
  • Width: 1452 mm
  • Height: 848 mm
  • Depth: 348 mm
Width With Stand 1452 mm / 57.1654 in
Height With Stand 848 mm / 33.3858 in
Depth With Stand 348 mm / 13.7008 in
Weight With Stand 23.5 kg / 51.81 lbs
Shipping Carton Measurements 5
Specification Value
Box Dimensions
  • Width: 1645 mm
  • Height: 1007 mm
  • Depth: 170 mm
Box Width 1645 mm (millimeters)
Box Height 1007 mm (millimeters)
Box Depth 170 mm (millimeters)
Box Weight 30.5 kg (kilograms) / 67.24 lbs (pounds)
Exterior Styling & Stand Footprint 2
Specification Value
Stand Width 863.6 mm (millimeters) / 86.36 cm (centimeters) / 34 in (inches) / 2.8333 ft (feet)
Chassis Color Off White Bezel and Light Wood Frame
Wall Mounting & Installation 9
Specification Value
VESA Mount 400 x 400 mm
VESA Interface 400 x 400 mm
VESA Size 400 x 400 mm
Removable Stand Yes
Height Adjustment Yes
Swivel Adjustment No
Tilt Adjustment No
Pivot Adjustment No
Portrait Mode No
Electrical Load & Efficiency 7
Specification Value
Power Input
100 V - 120 V (volts)220 V - 240 V (volts)
AC Frequency 50 Hz - 60 Hz (hertz)
Typical Power Consumption 69 W
Average Power Consumption 69 W
Maximum Power Consumption 175 W
Standby Consumption 0.5 W
Energy Efficiency Class E
Environmental Operating Limits 4
Specification Value
Operating Temperature 5 °C - 35 °C (degrees Celsius) / 41 °F - 95 °F (degrees Fahrenheit)
Operating Humidity 20 % - 80 % (percent)
Storage Temperature -15 °C - 45 °C (degrees Celsius) / 5 °F - 113 °F (degrees Fahrenheit)
Storage Humidity 10 % - 90 % (percent)
Picture Feature Inventory 2
Specification Value
Wide Color Gamut Yes
Dynamic Tone Mapping Yes
Gaming Validation & Compatibility 3
Specification Value
AMD FreeSync Certification Yes
Game Bar Yes
ALLM Yes
Regulatory & Industry Approvals 1
Specification Value
CE Game Accelerator 240 with Dual Line Gate technology
In-the-Box Components 5
Specification Value
Remote Control Voice remote control
Remote Voice Control Yes
Screen Size 64.5 in
Response Time 3.9 ms (milliseconds) / 0.0039 s (seconds)
Input Lag 5.8 ms
⚡

Estimated Running Cost

Based on this product's rated power draw, not an independent lab measurement — actual usage varies with settings and content.

Daily—
Monthly—
Annually—

Draws more power than 82% of the 447 comparable displays we track.
